NGC5033 Water Bug Galaxy

Category:Deep Sky
Published:
400
NGC5033 Water Bug GalaxyNGC 5033
Resolution:
1834x1350 px
File size:
681 KB

Photo description / processing

This work was done specifically to compare two telescopes using the not very large galaxy NGC 5033 (10.7'x5.3'): the Askar SQA 106 (509 mm f/4.8) and the Celestron Edge HD 8 (1400 mm f/7, with a 0.7 focal reducer). The cameras, however, are different: the Askar used a ZWO ASI 183 MC with 2.4 µm pixels, while the Celestron used a ZWO ASI 2600 MC with 3.76 µm pixels. The integration time is also different: 3 h 30 min for the Askar and 4 h 50 min for the Celestron. I'm not drawing any conclusions—judge for yourself.

Technical information

Telescope/Lens
Askar SQA 106
Camera
ZWO ASI 183 MC Pro
Mount
iOptron HAE43 C
Guide Scope
Askar 52mm F4
Guide Camera
ZWO ASI 120 MM mini
Software
SharpCap 4.0, Siril, Adobe Photoshop
Location
Адыгея, Станица Даховская, Россия

Light pollution

Green, Bortle 4 zone

Date taken

Exposure

  • 42 × 300″ · ISO/Gain: 120 ·

Total exposure: 3 h 30 m

Photo versions

NGC5033 Water Bug Galaxy
Current photoUpdated
NGC5033 Water Bug Galaxy

May 31st, 2026

3 h 30 m

This work was done specifically to compare two telescopes using the not very large galaxy NGC 5033 (10.7'x5.3'): the Askar SQA 106 (509 mm f/4.8) and the Celestron Edge HD 8 (1400 mm f/7, with a 0.7 focal reducer). The cameras, however, are different: the Askar used a ZWO ASI 183 MC with 2.4 µm pixels, while the Celestron used a ZWO ASI 2600 MC with 3.76 µm pixels. The integration time is also different: 3 h 30 min for the Askar and 4 h 50 min for the Celestron. I'm not drawing any conclusions—judge for yourself.

NGC5033 Water Bug Galaxy
NGC5033 Water Bug Galaxy

May 13th, 2026

4 h 50 m

Haven't shot deep-sky with the old, good Celestron Edge HD 8" for quite a while, and I'm already preparing material on the same object with the Askar SQA 106 telescope. It will be interesting to compare.

Show changes
Previous version
Current version

Comments

yas
In both cases, is the binning 1x1? How were the images aligned to the same pixel scale — if using AlignByCoordinates, which of the two was used as the reference?
