M94 - Cat's Eye Galaxy

Category:Deep Sky
Published:
1344
M94 - Cat's Eye GalaxyNGC 4736
Resolution:
2429x2428 px
File size:
276 KB

Technical information

Telescope/Lens
Sky-Watcher 2001
Camera
ZWO 183MC Pro
Mount
iOptron GEM28
Guide Scope
SVBONY SV165
Guide Camera
ZWO ASI 120MM mini
Accessories
2" Baader MPCC Mark III2" Antlia Triband RGB UltraZWO ASIAIR Mini
Software
Siril, Sirilic, Starnet++, Seti Atro Suite, GraXpert, Photoshop
Location
Курск, Россия

Light pollution

Orange, Bortle 6 zone

Date taken
t.me/pepepaintswh/210

Exposure

  • 110 × 60″ · ISO/Gain: 120 · 04.04.2025
  • 207 × 60″ · ISO/Gain: 120 · 23.04.2025
  • 95 × 120″ · ISO/Gain: 120 · 25.04.2025
  • 320 × 60″ · ISO/Gain: 120 · 27.04.2025
  • 65 × 60″ · ISO/Gain: 120 · 28.04.2025

Total exposure: 14 h 52 m

Comments

Ryjov Aleksey
Something is wrong with the processing. The main part of the galaxy, the outer ring, is completely missing(( The exposure is more than sufficient, and the telescope and camera are also very good.
Reply

Sign up or sign in to leave a comment.

Le_GushquaReply to Ryjov Aleksey
Yes, it's a shame about the outer ring. I suspect two things: 1) the filter—Oleg Novoselov had the same issue with this galaxy using the same filter. And second, I think the exposure doesn't match the light pollution level well. But I can't rule out my own mistakes either. It's probably a combination of all these factors. If you're interested, I can share the raw file—maybe something can be salvaged from it.
Reply

Sign up or sign in to leave a comment.

Ryjov AlekseyReply to Le_Gushqua
I can give it a try. I don't have a PixInsight license, so that makes it doubly interesting. Send me a link to Yandex Disk if you can, I'll try it out in the coming days. And what's your name, by the way? So we can get acquainted.
Reply

Sign up or sign in to leave a comment.

Le_GushquaReply to Ryjov Aleksey
https://drive.google.com/file/d/11s3r8TIC60eramyzSzeaSbELFY4lS3nI/view?usp=drive_link
Pavel, nice to meet you.
Reply

Sign up or sign in to leave a comment.

Ryjov AlekseyReply to Ryjov Aleksey
Pavel, unfortunately, the ring just doesn't stretch out. It's simply not there in the original stack, and there are clearly two reasons for this. First, it's definitely the filter. For this camera (I have the same one), I use a regular IR CUT filter. Second, yes, gain 120 is optimal, but the exposure should be at least 3 to 5 minutes (good guiding is needed). There's also a third possibility: heavy skyglow, but I doubt that's it. The ring should have shown up anyway—14 hours is a huge total exposure. Give me your email, I'll send you my M94 stack so you can see. Everything is clear there right away, and also what I tried while attempting to stretch your ring. And let's subscribe to each other.
Reply

Sign up or sign in to leave a comment.

Le_GushquaReply to Ryjov Aleksey
I completely agree. I've added plans for about 6 hours of shooting through Irkutsk to the imaging schedule. I think the final result should turn out pretty well, but I doubt the mount can handle such long exposures—the 200 Newton is a bit too large for it, and the pixel size is small too. It's better to write in Telegram: https://t.me/Le_Gushqua
