SNR G116.9_00.1, LBN 576, Abell 85 "The Last Breath of Mr. PZh" Final sum

 Posted: Oct 15th, 2026
Show astrometry on hover
NGC
IC
HD
Technical Info
Telescope/Lens: Прямофокусник 300/996 "Изд.№3" & SharpStar 13028HNT
Camera: ToupTek ATR2600M, ToupTek ATR2600C, QHY5III585M
Mount: МТ-120
Guide Scope: ED kenko 60 -400mm
Guide Camera: T7m
Software: NINA, Pixlnsight, ФШ
Accessories: GPU 1.0
Exposure:
143 x 300" ISO/Gain: 177 - Scorpio Ha-3nm
103 x 300" ISO/Gain: 177 - Scorpio Oii-3nm
50 x 30" ISO/Gain: 9 - R- ToupTek
50 x 30" ISO/Gain: 9 - G- ToupTek
50 x 30" ISO/Gain: 9 - B- ToupTek
184 x 180" ISO/Gain: 9 - Ha-6.5nm ToupTek
156 x 180" ISO/Gain: 9 - OIII-6.5nm ToupTek
15 x 600" ISO/Gain: 152 - Optolong L-Ultimate
98 x 300" ISO/Gain: 152 - Optolong L
Orange, Bortle 6 zone:
 Ekaterinburg Rayon Ozera Gluhoe, Russia
 Oct 10th, 2026
49 h 25 m
13
Resolution: 6056x3936 px
Scale: 8123 KB
Combined all the footage from '25 and this year into a single frame — with this, I'm done shooting this object.
Noise is a bit lower, oxygen is a bit more, but it's at the level of a glitch — after all, this is a fairly faint object for my light pollution.
So:
2025 imaging — scope Pryamofokusnik 300/996 "Ed. No. 3", color camera Touptek IMX 571 C, filter Optolong L-Ultimate, integration 10h 40min
2026 imaging — scope Pryamofokusnik 300/996 "Ed. No. 3", mono camera Touptek IMX 571 M, filters Scorpio Ha-3nm and Oiii-3nm, integration 20h 15min
In parallel, on the same mount, hung a SharpStar 13028HNT scope, with a QHY5III585M camera and a Touptek filter wheel, filters also Touptek RGB and HO-6.5nm — from it we got 17 hours 15 minutes of integration. I couldn't synchronize with the guide scope, so I just threw out bad frames that fell on dithering and on meridian flips.
Total combined integration: 49 hours 15 minutes.
I took the stars from the SharpStar 13028HNT, since it has a filter wheel, and on the big telescope with a filter slider I just didn't manage to shoot them.

LBN 576 \ (or SNR G116.9+00.1, Abell 85 and CTB 1) — a faint supernova remnant located almost 10,000 light-years from Earth. It is also estimated to be about 10,000 years old. Until recently it was considered a planetary nebula, but recent studies confirm that it is a supernova remnant, the closest known to Earth. This object, also called the Burnt Air Balloon or the Medulla Nebula, is the remains of ejecta formed during a supernova explosion. The expanding shock wave of material interacts with a large gas cloud, causing various elements such as hydrogen, oxygen, and sulfur to emit light at specific wavelengths. The image also includes a large emission nebula consisting of several massive clouds of gas and dust.
