M31 Andromeda

 Posted: Nov 11th, 2023
Show astrometry on hover
NGC
IC
HD
Technical Info
Telescope/Lens: Sky-Watcher 80ED
Camera: SV405CC
Mount: Vixen Sphinx SXW (deep modification)
Guide Scope: Finderscope 9*50
Guide Camera: T7m
Software: NINA/PHD2/Siril/FITStacker/PS.
Accessories: SV193 2 inch Reducer/Flattener 0.8x
Exposure:
109 x 300" ISO/Gain: 121 - Optolong L-Pro
Orange zoneLight Pollution:
 Barnaul, Russia
 Nov 5th, 2023
9 h 5 m
1373
I captured 2 hours and 15 minutes with the Svbony sv220 dual band 7nm narrowband filter, right under the northern lights.
Resolution: 3403x2357 px
Scale: 36083 KB
Current photo Updated
  11 Nov, 2023
  9 h 5 m
Добил 2ч15мин узкополосником Svbony sv220 dual band 7nm, аккурат под северное сияние попал.
  10 Oct, 2023
  6 h 50 m
Show changes
Add comment

Comments

Great photo! How did you manage to pair the Edehu with the Svbony reducer?
27 Jan, 2025 Reply
Ivvan22 Replied to Mikelazer
Thank you! Yes, everything is working normally. I tried adjusting the back focus because something resembling astigmatism appears at the edges, but moving it closer or farther from the calculated 55mm didn't improve things, so I left it at the standard spacing. I kept this reducer from the 80mm Svbony.
27 Jan, 2025 Reply
Mikelazer Replied to Ivvan22
I have an old (still blue) ED80 from Sky-Watcher and I'm puzzled about buying a reducer-flattener. The original one is no longer available, so I have to look for third-party options. SVBONY's price is more affordable. Thanks for the information.
27 Jan, 2025 Reply
Ivvan22 Replied to Mikelazer
As far as I understand, only the native lens can achieve the most beautiful results; everything else can be adapted to some extent, but with nuances regarding the stars.
28 Jan, 2025 Reply
Nickolay Replied to Ivvan22
I'm using the 503 102mm Svbony with the included extension tube, but there's no ring like for the 80mm. Still, it seems to do its job, though I'm just learning and don't have any decent shots yet.
26 Jul, 2025 Reply
