Jupiter 03.01.25 through various filters

 Posted: Jan 5th, 2025
Technical Info
Telescope/Lens: МАК 127/1500 mm
Camera: ZWO ASI 224MC (color)
Mount: Celestron NexStar 127 SLT
Guide Scope: нет
Software: SharpCap 4.1, ASIVideoStack_V1.11
Accessories: UV/IR Cut, IR-Pass 685 nm SvBONY, ZWB3 (UG5) Filter
 Moskva Yugo-Zapadnaya, Russia
 Jan 3rd, 2025
688
I photographed Jupiter using various filters, from left to right:
1. UV (conventional) - ZWB3 glass, transmission peak in the UV region at 334 nm (not less than 85%), transmission peak in the IR region at 700 nm (not more than 65%), no transmission in the visible range from 450-650 nm;
2. UV/IR Cut filter SvBONY;
3. IR - IR-Pass 685 nm filter SvBONY.
Resolution: 652x364 px
Scale: 55 KB
