M 106 (NGC 4258)

 Posted: Sep 17th, 2026
Technical Info
Telescope/Lens: Sky-Watcher 200 PDS
Camera: ZWO ASI294MM Pro
Mount: Sky-Watcher EQ6-R PRO
Guide Scope: Svbony SV106 F4 60/240
Guide Camera: ZWO ASI662MC
Software: PixInsight, RC-Astro plugins
Accessories: MEYON F4/5 1x 2-inch MPCC
Exposure:
14 x 300" ISO/Gain: 100 - Antlia V Pro L
10 x 300" ISO/Gain: 100 - Antlia V Pro R
10 x 300" ISO/Gain: 100 - Antlia V Pro G
12 x 300" ISO/Gain: 100 - Antlia V Pro B
 Mezmay Solnechnyy Veter, Russia
 May 25th, 2025
3 h 50 m
115
Resolution: 3660x2254 px
Scale: 14397 KB
One of the first objects shot with a monochrome camera. The flat frames turned out unsuccessful. I didn't think there could be any nuances with monochrome and that they might simply not apply oO Of course, I found out about this after the fact and couldn't reshoot them, which is why I had problems removing gradients. Also, the number of frames is not large, which didn't allow me to completely eliminate satellite trails. However, this is not a representative work. But after decent processing, it turned out quite well.

I previously published this object shot with an updated setup. So you can compare these two works with each other. The only difference is in the cameras and coma correctors. But both here and there have the same resolution of 1"/px
Add comment

Comments

Oops. I messed up and didn't mirror the galaxy vertically) And last time I didn't mirror it horizontally either) Too bad there's no rotation or mirroring in the editing.
17 Sep, 2026 Reply
Defects from bad flats don't really seem noticeable, but the satellite trails... I'd say, with that many frames they should be fairly well removed. Maybe it's a matter of the settings? Other than that, a very decent shot.
27 Sep, 2026 Reply
