WR 134 and WR 136 mosaic

Category:Deep Sky
Published:
165
WR 134 and WR 136 mosaicNGC 6874NGC 6871NGC 6881NGC 6883NGC 6888IC 4996
Resolution:
7526x5487 px
File size:
20903 KB

Photo description / processing

I started shooting the crescent and an idea came to mind — why not make a mosaic. I aimed, one might say, by eye using a photo from my phone; the rotation angle was the same, so I didn't miss by much. This was my first experience assembling a mosaic, and I didn't immediately understand how to do it properly in Siril. It took an hour to get the hang of it, and everything aligned and then merged correctly by layers. Of course, I cropped the frame quite a bit, but I gained invaluable experience and want to repeat it more deliberately. I kept the balance by having the same number of frames in each panel; I just didn't manage to capture the crescent.

Technical information

Telescope/Lens
Askar 71F
Camera
ZWO ASI2600MM PRO
Mount
JUWEI 14
Guide Scope
ToupTek GS-200 AR
Guide Camera
Zwo ASI662MC
Accessories
CAA, EAF, EFW, ASIAIR MINI, Askar Reducer x 0.75, Gemini PowerBox
Software
Siril, Adobe Lightroom, StarNet++
Location
Самара, Россия

Light pollution

Orange, Bortle 6 zone

Date taken

Exposure

  • 26 × 300″ · ISO/Gain: 100 · Antlia EDGE Ha 4.5 nm ·
  • 30 × 300″ · ISO/Gain: 100 · Antlia PRO OIII 3 nm ·

Total exposure: 4 h 40 m

Comments

Nickolay
We need to be friends) otherwise I shoot the surroundings of the star Sadr at 135 mm and also had the thought, what if I make a mosaic of Cygnus with the Samyang and 533 MC Pro, I have two panels Sadr-Crescent and Sadr-Tulip, so I want to do the stitching, I don't know how yet, I haven't even raised this question yet.
Reply

Sign up or sign in to leave a comment.

Nickolay
Yesterday I shot roughly the same frame, but there the Tulip is even farther away)
Reply

Sign up or sign in to leave a comment.

poppy8micro
In Siril there's nothing complicated. You just need to load a bunch of already calibrated frames into one sequence, and apply the astrometric solution to the whole sequence before registration. Then in the registration window select maximum overlap and it will assemble the mosaic image itself. With the 533 it should work well. The main thing is calibration and that the background is even everywhere without clouds over half the frame.
