Moon (pano)

 Posted: Jul 17th, 2025
Technical Info
Telescope/Lens: Sky-Watcher 130/650 PDS
Camera: ZWO ASI 462MM
Mount: Sky Watcher EQ3-2 onStep
Software: ASICap, AutoStakkert, SIRIL, Photoshop
Accessories: ZWO EFW, ZWO EAF, Линза Барлоу НПЗ х2
Exposure:
3000 x 0.001" ISO/Gain: 90 - Optolong R
 Ryazan, Russia
 Jun 1st, 2025
471
First experience of a panorama with more than 3 panels.
14 panels, each with 500 frames out of 3000.
Resolution: 3432x5865 px
Scale: 4648 KB
Add comment

Comments

Did ASICap help with the mosaic? Yesterday I tried to create a panel using ASIAIR, but with a small sensor and a limited view through the balcony window, I couldn’t properly perform a plate solve to make the telescope point accurately at the desired area I created and selected in the ASIAIR mosaic. It’s a pity that in this Plan mode you can only take photos.
18 Jul, 2025 Reply
Ho1den Replied to Oeswww
No, I captured the original frames "by feel." Regarding the ASIAIR—I can't properly polar align it from my balcony because polar alignment requires 30 degrees between each point, and one of the points always ends up on my window frame. But in the yard, after aligning with an error of 0.5 degrees (which is quite large), it still aimed fairly accurately. I’ll try to take the 61EDPH out in September and test the panorama feature in ASIAIR—I’m really curious to see how it works.
18 Jul, 2025 Reply
