Solar CaK

Category:Sun
Published:
191
Solar CaK
Resolution:
1768x1216 px
File size:
1710 KB

Technical information

Telescope/Lens
Vixen 90/1000
Camera
ZWO ASI1600MM
Mount
Sky-Watcher NEQ6 PRO SynScan
Guide Scope
No guiding
Guide Camera
n/a
Accessories
DIY CaK filter (1A)
Software
FireCapture, AS4!, imppg
Location
Junortoun, Australia
Date taken

Comments

Polyakov Aleksey
Hi Ken! Tell me more about the DIY CaK filter.
Reply

Sign up or sign in to leave a comment.

Ken HarrisonReply to Ken Harrison
(Edit)
I have a 2" Baader CCD Blue filter (#245847B) sitting about 60mm in front of the stack as an ERF.
Then a 1.25" Omega 40nm 394nm, an Omega 390nm UV cut, and then a Omega 2A 393.7nm. The final filter is a #1 filter (yellow) from a CaK PST.
Last time I measured the bandwidth it was around 1A centered just to the blue side of the CaK core.
Reply

Sign up or sign in to leave a comment.

Polyakov AlekseyReply to Ken Harrison
This is a very interesting set of filters! I bought an Omega CaK filter on eBay about 12-15 years ago, but I didn't know how to use it properly and sold it because the result looked more like a photosphere. I'm currently using the Lunt CaK + Antlia CaK + Antlia ERF. Overall, I like it; it allows me to see prominences in calcium. I especially enjoy shooting timelapses in calcium and hydrogen.
Reply

Sign up or sign in to leave a comment.
